Lab Non-Contact Optical Measurement Device (EV-2515)

1 / 5

Lab Non-Contact Optical Measurement Device (EV-2515)

Customization:	Available
After-sales Service:	18 Months Warranty
Warranty:	18 Months Warranty

Send Inquiry

Product Description

📊 Basic Specifications

Model NO.

EV-2515

Magnification

0.7X~4.5X(28X~180X)

Illumination

Adjustable for Surface/Contour

Power Supply

AC110-240V, 50Hz, 30W

Linear Scale

0.5µ M Resolution

Accuracy

(3+L/75)µ M

Repeatability

0.003mm

Software

2D Measurement Software

Trademark

Leader

HS Code

9031802000

🔍 Lab Non-Contact Optical Measurement Device (EV-2515)

The EV-2515 is a high-precision photoelectric measuring system equipped with a high-resolution CCD, continuous zoom lens, and precise linear scales. It is designed for maximum efficiency in quality control across various precision industries.

✅ Key Features & Usage

📍Applications: Electronic, molding, spring, screw, plastic, rubber, PCB, and lead frame industries.

📍Video System: High-resolution video camera for crystal clear imaging.

📍Digital Readout: DC3000 DRO systems with RS232 output.

📍Z-Axis: 0.5µ M resolution linear scale.

📋 Technical Parameters Comparison

Model No.	EV-1510	EV-2010	EV-2515	EV-3020	EV-4030
Travel-X. Y axis (mm)	150*100	200*100	250*150	300*200	400*300
Travel-Z axis	150	150	150	150	150
Resolution	0.5µ m	0.5µ m	0.5µ m	0.5µ m	0.5µ m
Stage size	354*228	404*228	500*330	500*330	606*466
Net weight	98kg	108kg	120kg	138kg	238kg

🛡️ Quality & After-Sales

Quality System

ISO9001 quality management system.
Full CE Certification for all machines.
Precision hardware adjustment for guaranteed linear accuracy.
Professional technical debugging and assembly.

After-sale Service

Free professional operation training.
Extended 18-month warranty.
Free regular software upgrades.
Lifetime technical support.

FAQ

Q1: What is the measurement accuracy of the EV-2515? A1: The accuracy is ± (3+L/75)µ M, where L is the length of the workpiece in millimeters.

Q2: Does the device support software upgrades? A2: Yes, we provide regular 2D measurement software upgrades free of charge.

Q3: What industries is this optical measurement device suitable for? A3: It is ideal for electronics, molding, springs, screws, plastics, rubber, and PCB industries.

Q4: What is the resolution of the linear scales? A4: All X, Y, and Z axes feature a high resolution of 0.5µ M.

Q5: How long is the warranty period? A5: We offer an industry-leading 18-month warranty for our measuring machines.

Q6: Is technical training provided? A6: Yes, free professional operation training is included to ensure perfect usage.
